Alpha Marathon’s ALPHA-CF cast film lines are designed to deliver exceptional quality and efficiency, whether producing mono or multilayer films. Each system is engineered with the flexibility to meet the ever-changing demands of our customers, ensuring adaptability for a wide range of applications.

Our Cast Film Systems represent total system engineering excellence. From material feeding to film winding, every component and control in Alpha Marathon’s systems is designed for reliability and flexibility, capable of handling variations in your product mix with ease. The advanced control package offers complete oversight of line operations, simplifying production while enhancing consistency and reliability.

We offer a variety of Cast Film line configurations, including:

• Gravimetric Feeding and Control
• Smooth Bore and Groove Feed Extruders
• Automatic Flat dies with Feedblocks (fixed and variable geometry) with or without Edge Encapsiulion
• Decklings (fixed or adjustable)
• Die Support for Easy Clening
• Dual Chamber Vacuum Box
• Air Knife of or Soft Box
• Electrostatic or Air Pinners
• Gauge Scanner (X-Ray, IR, Capacitance) and Comprehensive Software
• Various Treater Stations with Capability of 2-sides Treatment
• Slitting Station
• Film Rrandomizing System
• Surface or Turret Automatic Winders
• Automatic Core Insertion and Roll Unloading Systems
• Trim Suction System or Trim Winders
• Trim Pelletizer
• AlphaMatic Full Line Control, Including Alarms, Parameter Trends Current and Historical
• All Necessary Safety Features.
• The line complies with UL, SCA or CE

Alpha Marathon is always ready to customize or design entirely new systems tailored to your specific needs.

Applications for ALPHA-CF Cast Film Lines:

• Packaging and food films (barrier and non-barrier)
• Industrial films
• Stretch films
• Medical and pharmaceutical films
• Film for lamination

The following resins can be processed with ALPHA-CF Cast Film Lines:

LDPE, LLDPE, HDPE, mPE, mLLDPE, EVA, EMA, PP, Ionomers, PA-6, PA-66, PA-666, EVOH, Tie Resins, TPU, PETG, PS, different Bio-Based and Bio-degradable resins, PVOH

Alpha Marathon's blown film lines are the ideal solution for diverse production requirements, backed by a commitment to innovation and customer-centric design.
